Description
IntegraRack IR-35A Adjustable BallastRack™ Solar Module Racking System (Single Frame)
The IR-35A is the fastest and easiest ground mounting system available and allows for modules of any size to be racked and adjusted from 15-35° for optimal year-round energy production. This system can be mounted almost anywhere with its four available mounting options and is strong enough to withstand incredible wind and snow loads (See Datasheets & Engineering for more detailed ratings on this system). The IR-35A is also the lowest cost per Watt option on the market, with only one IR-35A Frame needed per solar module after starting the row, and no pouring of concrete footings required. The minimal and modular design allows for good airflow behind the solar panels to optimize efficiency and avoid energy heat loss common with plastic bin type products.
*The IR-35A is not interchangeable with other BallastRack Products
*Not intended for seasonal angle adjustment
See how fast this product can be installed: (Video) Ten Panels Installed In 100 Minutes
How many frames do you need?
(NUMBER OF PANELS) + (ROWS OF PANELS) = (FRAMES NEEDED)
EXAMPLE: (30 PANELS) + (3 ROWS OF TEN) = 33 Frames
– Adjustable Angle
- Each IR-35A Frame can be adjusted from 15-35° Degrees
- Set system to optimal year-round sun angle in your region
– Fast Assembly & Install
- 2 minute assembly per IR-35A Frame
- Installation as fast as 10 minutes per module
- No earth augers, no concrete, and no post ponding required
- Only one main frame component is required between each solar module to complete entire ground mount system
– Universal Mounting
Four Mounting Options (Click links to view more information):
- IR EarthBallast™ Kit – Uses fast setting epoxy to adhere geotextile material to IR-35A Frames and earth fill over for a fast ballasted system
- IR AnchorSpike™ Kit – Mount IR-35A Frames by clamping the base tubes around specially designed anchor spikes that provide easy off the ground leveling
- Concrete Lag Bolt Kit – Bolt the IR-35A Frames directly to any concrete surface (concrete pad, footings, or patios)
- Base Ballasting – Hold IR-35A Frames in place using flat water tanks or concrete curb stops
– Most Cost Effective Ground Mounted Solar System
- One of the lowest cost per Watt ground mount racking systems on the market
- Traditional ground mount solar racking systems take 6x longer to install and are much more labor intensive
- Capable of racking modules of up to 700 Watts
– High-Strength Engineered & Tested
- Extensively engineered and outdoor lab tested with simulated real world wind and snow load conditions
- Build entirely from aircraft grade 6061 T6 aluminum with stainless steel mounting brackets
- Capable of withstanding incredible wind and snow loads (click manufacturers resources link below for detailed Datasheets)
- Strong, simple “U” shaped design provides amazing strength
– Unprecedented Versatility
- Adjustable angle from 15°-35° for optimal year-round energy production and excellent snow shedding capabilities
- Up to 2 feet of ground clearance
- Adjustable solar module height
- Portrait solar module mounting for easy wiring
- The Base Tubes of each IR-35A Frame are designed to clamp around and bite into IR AnchorSpikes or concrete stakes for easy leveling and increased hold down strength.
Additional Info
Click HERE for additional Product Info, Instructional Videos, Warranty Coverage, Datasheets, Testing & Engineering for the IR-35A BallastRack.
Additional Components Required For Some Mounting Configurations
1 Inch EMT/Conduit Pipe (required for certain mounting options)
- 1 inch EMT adds racking strength and helps with positioning for module spacing.
- 10 foot long Conduit Pipes can be sourced locally (Home Depot, Lowes, Electrical Hardware Store, Etc.).
Are you a licensed solar installer?
Click HERE to apply for our Authorized Dealer/Installer program to see if you qualify for discounted pricing and referrals.
